- Size: 13
- Place of Origin: JINAN
- Brand Name: Suke
- Model Number: SK-1325
- Weight: 1200.000 kg
Working area: 1300*2500*300mm
Heavy duty structure with 8mm thickness steel
Italy HSD 9.0kw air cooling spindle with auto tool change
Japan servo motors and drivers
Delta inverter
Original Taiwan Syntec the best controller
Schneider Electronics from France
Omron limited switch from Japan
T-slot & vacuum combination table
Taiwan TBI ball screw
Professional tool box
oil injection system
Tool sensor
Powder coating technology to avoid damage
- Size: 13
- Place of Origin: JINAN
- Brand Name: Suke
- Model Number: SK-1325
- Weight: 1200.000 kg
The parameter of best 1325 wood cnc carving 3 axis pvc table machine router price
Model | SK1325C Auto Tool Changer ATC cnc router |
Working area | 1300X2500X200mm |
Table structure | T-slot & vacuum combination table |
Working accuracy | 0.02mm |
Repositioning accuracy | 0.02mm |
Transmission | X and Y axis by rack,, and Z axis by screw |
Max. No-load speed | 32m/min |
Max. Working speed | 25m/min |
Spindle power | 9.0KW Italian air-cooling spindle |
Spindle speed | 0-24000RPM |
Power supply | AC380V/50-60Hz |
Command | G code/mmg/plt/ |
Controlling system | Syntec EZ4 |
Dimension | 1840*3100*1800mm |
Total weight | Approx. 1500kg |
Spindle | Italian HSD 9KW air-cooled spindle |
Inverter | Taiwan Delta inverter |
Controlling system | Taiwan Syntec controlling system |
Motor | Servo motor from Yaskawa Japan |
Guide rail | Taiwan HIWIN square rails |
Vacuum pump | 5.5kw water vacuum pump |
Design software | Compatible with many software, such as Type3/Artcam/Castmate |
